Description
PERFORMANCE
Top Speed: Classes 1/2/3 Off-Road 28+ MPH
Range: 80 miles
Miles 40+ miles of range at 15 mph under Class 2 throttle-only 80+ miles of range using Class-1 pedal assist mode
Charge: Time 8-12hrs
Battery: 1200 W/H (52V – 25Ah) Cell Samsung 21700 Lithium-Ion
Motor: Brushless 1000w nominal / 1800w peak
Suspension: Full Forks Hydraulic Air Lock-out, Rebound Adjustable Travel (120-160mm)
Fram: Adjustable Air Ride Suspension (EXA FORM A5)
Brakes: GEMMA G3 Four-Piston Hydraulic Brakes
Tires: 20″ x 4.5″ Kenda Knight Puncture Resistance
Throttle: Twist on/off Button
Derailleur: Acera 7 Speed Shimano
Display: LCD Color (KT-LCD8H)
Grips: Impact Anti-Slip
USB: A Port
DIMENSIONS & WEIGHTS
Vehicle Weight: 67lbs
Battery + 14lbs
Length x Width x Height: 73″ x 27″ x 43-49″
Seat Height: 32″-39″
Rider Weight Limit: 330lbs
FRAMESET
Frame: Aluminum
Suspension: Full
LIGHTS & HORN
Lights: Dual LED Elements Headlight, Brake, and Tail Lights
Horn: Electric Horn
